General parameter

Vehicle Brand

ISUZU with ABS

Overall Dimension

8200×2490×3100mm

Total Mass

16000kgs

Kerb Weight

8200kgs

Cab

Cabin

two doors , power steering, electrical window

Air Condition

With

Engine

Model/Rated Power

6HK1-TCL

Displacement/ power

5193L /151kw （140HP）

Emission Standard

Euro 5

manufacturer

ISUZU motor Co., Ltd.

Diesel 4-stroke, 6-cylnder in line with water cooling

Chassis

driving type

4*2

Wheel base

4500mm

Front/rear tread

1960/1855

Front axle

 6.3T front axle

Rear axle

 13T rear axle

Brake system

 air cut brake

Gear box

ISUZU MLD six forwards

Type & Size of Tyre

295/80R22.5

Max Speed

90-120Km/h

SuperStructure

Capacity:

10,000Litres

Capacity: 10,000Litres

1. Compress garbage tuck in clued garbage carriage, sewage tanker, a packer, scraper, shovel, multi-way reversing valve and hydraulic system.

2. With convenient and efficient garbage collection function, automatically repeated compression and creep function, high compression ratio, large loading capacity, automatic operation, good sealing.

3. The dirty water is come into the sewage tank during compression; the main part is high quality imported parts.
