New ISUZU 4000L Milk Transportation truck
New ISUZU 4000L Milk Tank truck
1. ISUZU BRAND CHASSIS
With air condition,
power steering.
2.Color: White body and white cabin
3.Drive type: LHD
4. Engine : ISUZU4KH1-TCG40/ 120HP
5. 7.00-16 tyres
Capacity of tank body: 4000Litres
Food grade stainless steel
2 compartments
Website:www.isuzutruckcn.com
E-mail:pinky@runlitruck.com
Tel:+86 15897603919 (Whatspp)
Tel:
Fax:
Add:No.77, Century Ave., Suizhou City, Hubei, China
120HP 4K Engine ISUZU Fresh Milk Transportation Truck 4000L 1000Gallon
New ISUZU 5000L Milk Tank truck
1. ISUZU BRAND CHASSIS
With air condition,
power steering.
2.Color: White body and white cabin
3.Drive type: LHD
4. Engine : ISUZU4KH1-TCG40/ 120HP
5. 7.00-16 tyres
Capacity of tank body: 4000Litres
Food grade stainless steel
2 compartments
| Specification |
the specification of 120HP 4K Engine ISUZU Fresh Milk Transportation Truck 4000L 1000Gallon:
Products Technical Specification | |
Type | ISUZU 4000L Milk Tank truck |
Brand | ISUZU 4*2 |
Cab | Power steering, Air Condition |
Vehicle Description | |
Overall dimensions（mm） | 5800×1900×2600 |
Curb weight(vehicle) (kg) | 3800 |
Loading capacity (kg) | 4000 |
Max speed (Km/h) | 95-120 |
Engine | |
Mode | 4KH1-TCG40 |
Type | Diesel, 4-cylinder in line with water cooling, turbo-charging |
Max. power/rotated speed | 88kw 120HP |
Displacement(ML) | 2999ML |
Emission level | Euro 4 |
Chassis Description | |
Wheel base | 3360 |
Front axle | 2.5T |
Rear axle | 4.8T |
Front tread / rear tread | 1504/1425 |
Gear box | ISUZU MSB 5-speed |
Brake system | Air braking |
Operation control system | Power Steering |
Electric system | 24V |
Tyres | 7.00-16 |
Milk Tank Body | ||
volume of tank | 2,000Litres/ three compartment | |
1. Inside tank body: material 304-2B food grade material.
2. Polyurethane Foaming Thermal Insulation 80mm thickness 3. Outside cover stainless plate 1.2mm thickness. 4. Clean pipe for each compartment , food grade material pipe 5. Outside pipe for each compartment, food grade material pipe.
| ||
6. Clean pipe inlet : connect External water pressure, to clean each company by external water pressure. 7.outside valve for each compartment. Control by manual valve.
| ||
Clean pressure nozzle : fixed in each compartment, contact clean pipe ( No. 4). 360 degree rotation. To clean the inside of tank body.
Clean pipe and clean nozzle valve: when clean compartment, turn on this valve first. Each compartment install one clean nozzle valve.
When discharge all milk outside, should clean tank body by clean pipe, clean nozzle. | ||
Top of manhole, each compartment with one manhole | ||
Discharge outlet:
| ||
| Pictures |
Picture of 120HP 4K Engine ISUZU Fresh Milk Transportation Truck 4000L 1000Gallon:
